LINEAR SWITCHING POWER SUPPLY dimmable DALI-II/PUSH-DIM CV PWM 45 Watt

Number of ratings: 0

Item no: ERLS-45-24-DALI2-LI

Constant voltage power supply, dimmable via DALI-II or PUSH-DIM control, plastic housing, terminal connections, operating voltage 198-264 VAC, output voltage 24 VDC, output power 45 watts, MM mark / SELV, dimensions L 187mm, W 45mm, H 30.5mm, weight 0.25kg

Stock: 12 pc.

Datenblatt

Konstantspannungsnetzteil, dimmbar über DALI-II oder PUSH-DIM Ansteuerung, Kunststoffgehäuse, Klemmenanschlüsse, Betriebsspannung 198-264 VAC, Ausgangsspannung 24 VDC, Ausgangsleistung 45 Watt, MM-Zeichen / SELV, Abmessungen L 1870mm, B 45mm, H 30.5mm, Gewicht 0.25kg

Anleitung_LS-45-80-150_Netzeile.pdf

Bewertungen (0)

You have to be logged in to submit a review.

So bewerten andere Kunden diesen Artikel:

(

based on 0

Reviews)

Electrical data

operating voltage:198 - 264V

Power (watt):45

dimmable:Yes

interfaces

DALI:Yes

DALI-II:Yes

PUSH-DIM:Yes

Power supply and controller data

Exit Art:DC

Output voltage:24V

Load capacity in A per Ch:1.9

PWM-Frequenz:4000 Hz

Fan:without fan

Approvals

MM-symbol:Yes

F-sign:Yes

SELV:Yes

IP protection class:IP20

Dimensions

Width in mm:45

Height in mm:30.5

depth in mm:187
